Drilling Capabilities

Rig 7 Atlas Copco RD20 Range III Drilling Rig


Rig 7
Atlas Copco RD20 Range III Drilling Rig
RD20 IIITechnical specifications
Pullback (hook load)489 kN
Pulldown60.5 kN
Torque (top drive)35 kN @ 0-120 RPM
On-board Compressor35,000 l/m @ 24 bar
Mud / Air piping100 bar working pressure
Deck engineCummins QSK-19C 755 HP engine @1800 RPM
Nominal depth range1675 m
Carrier5.7m wheelbase, 39,010kg GVM

Rig 5
Hanjin D&B 16 Multi
SpecificationDescription
Rig Engine6 cylinder Hyundai 6BT turbo intercooled with 180 hp at 1800 rpm
Crawler Mounted BaseHydraulic powered Sola 55, crawl speed 2.5km/hour, ground pressure 0.5kg/cm2
Rig BodyOperators platform, four hydraulic stabiliser legs
Rig HydraulicsKawasaki K3V112, 280 bar operating pressure, 4 pump open loop system
Rotary DriveHanjin Gearbox - floating hollow spindle and hydraulic head lock and swing
Three Speed, 1000 rpm, 800 rpm, 120 rpm
Low speed torque to 4150 Nm, high speed torque to 966 Nm
Gearbox mounted outside mast to allow for drill pipe and casing handling
Feed SystemTraverse Cylinder 120mm x 90mm x 1900mm
Top head driven by heavy duty chain
Pull up capacity 16 tonne, Pull down capacity 8 tonne
Main WinchMaximum pull is 10 tonne
Capacity 30m of 14mm cable
Mast10744mm height, 7429mm travel
Supplied with hydraulic circuit with quick-connect couplings for optional breakout table
Coring PumpAW1122 horizontal triplex pump
Mud Pump5x6 Rock Smith piston mud pump
Break-out TableHydraulic drill pipe clamp and break-out table, break out torque 4 tonne
Control PanelAll controls/gauges are grouped at the operator’s station within site of the borehole

Drilling MethodMaximum Hole Depth (m)Maximum Hole Diameter (mm)
Rotary Air (Down-hole hammer)500300
Rotary Mud500350
HQ Wire-line Coring800-
Reverse Circulation100250

Mud Pumps
LW 446 Triplex Mud Pumps x 2, build dates July 2015 and Nov 2016
LW 446Technical specifications
Pump Type6 inch triplex
Capacity550 gpm @1200 psi - 280 strokes per minute
EngineCummins 446 HP engine @ 1,800 RPM
Charge Pump6 inch centrifugal
Pulsation Dampener700 psi, nitrogen charged
Pump layoutCustom built onto elevated trailer with built in hydraulic jack legs.


Downhole Geophysical Logging

The Impax Group has geophysicists and technical officers on staff who can conduct down-hole geophysical logging using a variety of logging tools.  Our in-house capability for down-hole geophysical logging offers the most comprehensive array of groundwater and exploration tools of any comparable group in Australia.

Downhole geophysical logging capabilities are as follows:

  • Design of geophysical logging programs;
  • Data acquisition using one of our dedicated logging units, which are mobile and can be set up at any drilling location.  A wide variety of logging tools can be used by our logging units, including (but not limited to):
    • Gamma tools;
    • Resistivity tools;
    • 3 arm caliper;
    • Temperature / flow;
    • Auto-logging winches to 1,000m
  • Collation and interpretation of captured data using industry standard software (well cad); and
  • Assessment of data and incorporation of data into the drilling program.

Rig 2 and Rig 3
Hydrapower Explorer 500 Drilling Rig
Rig BodyOperators and offsiders offsider's platform, four hydraulic stabiliser legs
Rig Hydraulics"Sauer Danfoss proportionally controlled control valves
Sauer Danfoss closed loop pump on Rotary Drive
Sauer Danfoss open loop pump on auxiliary functions"
Rotary Drive"Steel Casing with floating hollow spindle and hydraulic head lock and swing
Two Speed 0 - 225 rpm & 0 - 966 rpm
Low speed torque to 4150 Nm high speed torque to 966 Nm"
Head Travel"Feed / Stroke 9m
Rod Pull 8m"
Main Winch"Maximum pull is 10000 kg
Maximum line speed is 28 m/min"
Wire line Winch"Maximum pull is 1000 kg
Maximum line speed is 83 m/min"
Pull-downPull down capacity is 6000 kg

Drilling MethodMaximum Hole Depth (m)Maximum Hole Diameter (mm)
"Rotary Air
(Down-hole hammer)"500300
Rotary Mud500350
HQ Wire-line Coring800-
Reverse Circulation100250

Rig 1
Hydrapower Scout
Truck Mounted BaseIsuzu NPR 400 Long Wheelbase, GVM 7,500kg
Rig Engine4 cylinder Mitsubishi 30 hp at 2200 rpm
Rig HydraulicsSauer Danfoss proportionally controlled control valves
Sauer Danfoss open loop pump on auxiliary functions
Rotary DriveHydrapower Gearbox - Steel Casing with floating hollow spindle and hydraulic head lock and swing
One Speed Gearbox; 0 - 150 rpm rpm
Low speed torque to 600 Nm
Head Travel5.1m
Main WinchMaximum pull is 1500 kg
Maximum line speed is 28 m/min
Pull-downElectronically controlled with dial for speed control
Pull down capacity is 1500 kg
Pull out capacity is 1400 kg
MastMast length of 5.1m, with hydraulically operated breakout spanner and top pulley swivel
Sliding angle for non-vertical drilling
PumpOn-deck hydraulic powered fluid pump
Rig BodySupplied with operator's platform, two hydraulic levelling / stabilizer legs with burst valve protection and fuel tank.
ToolkitIndicator lights for rear of mast, mast lock plates, parts and maintenance manual for rig and engine, and hydraulic pump test point pressure gauges

Drilling MethodMaximum Hole Depth (m)Maximum Hole Diameter (mm)
Rotary Air100150
Rotary Mud100150
Auger - Solid Flight or Hollow Stem25150
